These output wires can also carry GPS and DSC NMEA sentences as well. The AIS data that is used by the internal display can also be used by external devices that support AIS by hooking up the radio’s AIS output wires to the other device’s input wires. No additional antenna splitter is required. Another major benefit is that you only need one VHF antenna connection to get both AIS and VHF radio support. To call an AIS vessel, you simply select the vessel on the display and hit the CALL button.
#Garmin nmea 2000 wiring full
With the built-in GPS, not only do you get full DSC functionality, but you also get a mini AIS display showing a radar-like view of nearby vessels. Standard Horizon has been making marine radios for years but last year it launched a new AIS Matrix radio that has integrated a dual-channel AIS receiver and a GPS receiver in a standard marine VHF radio form factor. Standard Horizon Matrix GX2200 AIS/GPS Receiver VHF Radio This is a great solution for enabling older marine electronics to work with and share data with newer NMEA 2000 compatible devices. And it works the other way as well by taking NMEA 2000 PGNs in and converting those to NMEA 0183 sentences that can then be used with older NMEA instruments. This means it can take NMEA 0183 data and convert the NMEA sentences to NMEA 2000 PGNs which are then pushed out on your NMEA 2000 network. It has 4 bare wires (2 input wires / 2 output wires) on one end for the NMEA 0183 connection and a NMEA 2000 plug on the other end which can be attached to a standard NMEA 2000 T connector on your NMEA 2000 network. The AMEC NK-80 is a NMEA 2000 to NMEA 0183 bi-directional gateway.
#Garmin nmea 2000 wiring how to
What this will enable is the ability to send AIS, DSC and even GPS data to a NMEA 2000 network from your GX2200 and also use an external NMEA 2000 GPS source with your GX2200 in case you do not get good GPS coverage where you have the GX2200 installed.īefore jumping into how to connect these solutions together, it is worth reviewing what each product does.
This article shows you how to easily add NMEA 2000 support to a GX2200 using the AMEC NK-80 NMEA 2000 Adaptor. But one thing that is missing is the ability to use this device with a NMEA 2000 network. This radio has built in AIS and GPS receivers and makes a nice self-contained AIS system - not to mention a great VHF radio.
The Standard Horizon GX2200 AIS Matrix VHF radio is one of our most popular products.
